BLACK - JB for Small Base
BLACK - JB for Small Base
luminum alloy material with surface spray treatment • Camera cables can be perfectly collected to the junction box so that the installation looks more elegant • Bottom inlet and side inlet • Available for wall or ceiling mounting
• Water-proof design
Model MV-JB-YXH0302
Material Aluminum alloy
Color White
Protection Grade IP66
Min. Packaging Quantity 20
Packing Size 375x330x310mm
Dimension 139.3x50mm
Load Bearing
The wall must be strong enough to withstand at least 3 times
the weight of the camera and the junction box
Net Weight 512g
Working Temperature -40°C~+60°C(-40°F~+140°F)
Working Humidity 10%~90%
